    Xenon Lamp Aging Environmental Testing Machine For Fabric Weather Resistance OEM ODM Customized And Stable

    Xenon Lamp Aging Environmental Testing Machine For Fabric Weather Resistance Testing Chamber Customized And Stable

    Xenon Arc Test Chambers is a comprehensive climate testing machine, in addition to climatic aging test, the light fastness of materials can be carried out to test, polymer materials exposed at simulated sunlight. It simulates the light, temperature, rainfall, condensing, humidity to test the materials; it can be used for choosing new materials, improving existing materials, or assessment of change in material composition.
    Universal Standard IEC 68-2-9, Basic Environmental Testing Procedures; ISO 4892-1, Plastics-Methods of exposure to laboratory light sources ; ASTM G151,General Guidelines for Exposure of Nonmetallic Materials; ASTM G155, Xenon-Arc Test Apparatus for Exposure of Nonmetallic Materials. GB/T 16422.1 Automobile Parts SAE J2412, Accelerated Exposure of Automotive Interior Trim Components Using a Controlled Irradiance Xenon-Arc Apparatus SAE J2527, Accelerated Exposure of Automotive Exterior Materials Using a Controlled Irradiance Xenon-Arc Apparatus QB/T 2727, ASTM D7356, Standard Test Method for Accelerated Acid Etch Weathering of Automotive Clearcoats.
    Main functions:
    Xenon Arc Test Chambers make the samples exposed to the high temperature and alternating back to the circle of light and moisture environment to test the materials. This machine use xenon lamp tube to simulate the sunlight radiation, and use condensation water and spray water to simulate the dew and rain. This instrument only use a few days or weeks time, to realize the condition or the parts aging damage state in outside environment in few months or years. Including fade, color change, fracture, crack, wrinkle, foaming, embrittlement, strength reduction, oxidization and so on.

    Corresponding standard:
    ASTM G155-05a Standard Practice for Operating Xenon Arc Light Apparatus for Exposure of Non-Metallic Materials1

    Applicable industries:
    Applied to control the product quality, such as electronic, plastic products, electrical appliances, instruments, food, vehicles, metals, chemicals, building materials, aerospace, medical care and so on.

    Technical parameter:

    Model HZ-2011 Xenon Arc Test Chambers
    Testing room D×W×H 500*600*500mm
    Index Temperature range RT+10°C~80°C
    Humidity range 6598%R·H
    Spray time 19999min, adjustable
    Spray cycle 1-240min, interval adjustable
    Spectral wavelength 290nm800nm (60w/m2)
    Light source Xenon lamp (air-cooled)
    Xenon lamp power 1kw, 6kw (longevity: 1600H)
    Temperature and
    humidity control
    Time controller Import controller from Moeller
    Accurate range Temperature: ±0.1°C / humidity: ±0.1°CR·H
    Sensor Platinum resistance Pt100Ω/mv
    Heating system Independent system, nickel chromium alloy electric heating type heater
    Humidity system Stainless steel, external Isolated humidifier
    Blackboard temperature Bimetal thermometer blackboard 55°C~75°C
    Water supply Humidification water supply with automatic control, xenon lamp cooled by water recycling
    Temperature controller Import controller
    Humidity Irradiation: 30%~65%RH darkly: up to 90%RH
    Cycle system Low-noise air-conditioning-type motors, multi-leaf-type centrifugal wind wheel
    Material Outside material Advanced spray color plate /SUS304 stainless steel
    Inside material SUS304 stainless steel
    Sample holder material SUS304 stainless steel
    Insulation High and low temperature aging of silicone rubber
    Standard A set of radiation-proof glass window, dynamic testing sample shelf 1, xenon lamp tube 2
    Protector Leakage, short circuit, over-temperature, water shortages, motor overheating, over-current protection.
    Power AC380V±10% 50±0.5HZ, Three-phase five-wire system
    Environmental temperature ±5°C+30°C ≤85%R·H
