Universal Joint Drive Dynamic Balancing Machine 160KG Max Mass Of Workpiece For Centrifugal Impeller

    Buy cheap Universal Joint Drive Dynamic Balancing Machine 160KG Max Mass Of Workpiece For Centrifugal Impeller from wholesalers

    Buy cheap Universal Joint Drive Dynamic Balancing Machine 160KG Max Mass Of Workpiece For Centrifugal Impeller from wholesalers
    • Buy cheap Universal Joint Drive Dynamic Balancing Machine 160KG Max Mass Of Workpiece For Centrifugal Impeller from wholesalers
    • Buy cheap Universal Joint Drive Dynamic Balancing Machine 160KG Max Mass Of Workpiece For Centrifugal Impeller from wholesalers
    • Buy cheap Universal Joint Drive Dynamic Balancing Machine 160KG Max Mass Of Workpiece For Centrifugal Impeller from wholesalers

    Universal Joint Drive Dynamic Balancing Machine 160KG Max Mass Of Workpiece For Centrifugal Impeller

    Ask Lasest Price
    Brand Name : Lixian
    Model Number : HZ-9702A-1000
    Certification : CE, ISO 9001:2015
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 200sets/ month
    Delivery Time : 5-8 days
    Price : USD 1000~6900/per set
    • Product Details
    • Company Profile

    Universal Joint Drive Dynamic Balancing Machine 160KG Max Mass Of Workpiece For Centrifugal Impeller

    Universal Joint Drive Dynamic Balancing Machine 160KG Max Mass Of Workpiece For Centrifugal Impeller


    Dynamic balancing machine Description


    Universal Joint Drive Balancing Machine is an instrument used to determine the unbalance of the rotor. The balancing machine is a hard- supported balancing machine. The swing frame is very rigid. The measurement result of the dynamic balancing machine is used to correct the unbalance of the rotor, so that the vibration generated when the rotor rotates or acts on the vibration on the bearing is reduced
    to the allowable range to achieve the purpose of reducing vibration, improving performance and improving product quality.

    Dynamic balancing machine Range of Application

    This balancing machine is widely used in balancing rotatable bodies, such as kinds of good-sized and medium-sized motors rotors, impeller, fans, crankshaft, turbocharger, water pump, roller, grinding wheel, main shaft of machine tool , textile machinery, tool , spindle, etc .. Driven by belt, equipped with Variable speed motor to drive .Which ensures high quality balancing and precision. quick booting ,easy operation. and high efficiency . This machine is equipped with special fixtures and it is convenient to install. Its characteristics have the advantages of high precision, high efficiency, convenient operation, intuitive display, rapid measurement, stable performance, and the use of frequency conversion speed control device to control the speed. The electromechanical measurement system can be equipped with a microcomputer digital display measurement system or a computer measurement system.


    Model Number
    HZ-9702A-1000
    Max Mass of Workpiece(kg)
    160 kg
    Max Diameter of Workpiece
    1250 mm
    Transmission flange to right support spacing range (mm)
    700~1000rpm
    Workpiece axis neck range
    Ø50~ Ø120
    1LCD
    17 inch
    The smallest achievable residual unbalance (g.mm/min):
    ≤1
    Motor Power (KW)
    2.2
    Balance speed (r/min)
    Frequency conversion stepless speed regulation
    Balance reduction rate (%):
    ≥90%
    Control System
